10000V High Voltage Industrial Motor

32 Views

Our YKK(AMI) series high-voltage three-phase asynchronous **Industrial Motor** is a mature **Heavy-Duty Motor** developed with over 70 years of professional motor manufacturing experience. With frame heights from 355mm to 1120mm, it covers a power range of 0.55KW to 20000KW and voltages from 380V to 13.8KV, with the 10000V model as our standard specification. Optimized via field-circuit coupling electromagnetic calculation and FEM finite element structural analysis, the motor achieves high efficiency, low vibration, low noise and strong overload capacity. It can be customized into dedicated models: **Motor for Ball Mill, Motor for Rolling Mill, Motor for Crusher, Motor for Steel Mills, Chemical Plant Motor, HVAC Motor** and anti-salt-fog **Marine Environment Motor**, fully meeting diverse **Mining Motor Application** and heavy industrial driving demands for mines, steel plants, chemical factories, power stations and marine projects.

We adopt premium raw materials for stable long-term operation, including pure copper stators, optional copper/aluminum rotors, ASTM1045 steel main shafts and world-class SKF/FAG bearings. A strict full-process quality control system is implemented: all raw materials and core components such as coils, iron cores, rotors and spindles undergo rigorous physical, dimensional and welding inspections. Every finished motor must complete mandatory routine tests including resistance, insulation, withstand voltage, vibration and noise detection. High-power customized heavy-duty motors will additionally pass strict type tests covering temperature rise, loss analysis and long overload endurance to guarantee performance under continuous harsh working conditions.

The motor features a standard 120-micron anti-corrosion paint finish, with reinforced coating available for chemical and marine working conditions. We provide professional export packaging suitable for long-distance ocean shipping. Our standard warranty lasts 12 months after commissioning or 18 months after shipment (whichever comes first), with flexible extended warranty options for 24/7 running heavy-duty equipment. Supported by complete after-sales technical service and spare parts supply, our high-performance heavy-duty industrial motors deliver reliable, cost-effective operation for global heavy industry clients.

Get a Quote

Category :

High Voltage Motors

Description

10000V High Voltage Industrial Motor | YKK(AMI) Series High-Voltage Three-Phase Asynchronous Motor

Product Overview

YKK(AMI) series high-voltage three-phase asynchronous Industrial Motor covers frame sizes from 355mm to 1120mm. Developed independently by our factory based on over 70 years of experience in manufacturing large and medium-sized high-voltage AC motors, this Heavy-Duty Motor absorbs and innovates upon advanced global motor technologies. We adopt modern comprehensive electromagnetic field simulation for electromagnetic calculation, conducting refined optimization for various losses, wind resistance and structural mechanical strength of all motor components. Supported by a mature and stable R&D and production system, premium raw materials and precise processing technology, our motors feature high efficiency, low noise, low vibration, outstanding reliability, easy installation and convenient maintenance.

With a wide power range of 0.55KW to 20000KW and voltage coverage from 380V to 13.8KV, our standard 10000V high-voltage model perfectly serves diversified heavy-load working conditions. Widely applied in petroleum, chemical industry, coal mining, power stations, metallurgy, transportation, textile, pharmaceutical and grain processing industries, our customized models include Motor for Ball Mill, Motor for Rolling Mill, Motor for Crusher, Mining Motor Application, Motor for Steel Mills, Chemical Plant Motor, HVAC Motor and Marine Environment Motor, perfectly driving fans, water pumps, compressors, crushers, slicers, conveyor equipment and other heavy machinery.

Product Features & Technical Advantages

Accurate Electromagnetic Design with Strong Overload Capacity Combining world-leading technologies, we apply the field-circuit coupling design method to greatly improve the precision of electromagnetic calculation and accurately set the maximum torque multiple. It delivers excellent overload performance, which is essential for Motor for Crusher and Motor for Ball Mill to handle instant impact loads in mining and metallurgical scenarios.
Finite Element Structural Analysis for Stable Low Vibration & Low Noise Operation Finite Element Method (FEM) mechanical analysis is adopted for structural design, verified by massive practical application cases. Accurate boundary conditions are applied to mechanical models to optimize material utilization and effectively suppress motor vibration and noise. This design is highly suitable for continuous impact working conditions of Motor for Rolling Mill and general Mining Motor Application, greatly reducing resonance failures. Meanwhile, FEM simulation optimizes multiple cooling structures with precise airflow distribution calculation, improving temperature rise accuracy, cutting ventilation loss and boosting the overall efficiency of every Industrial Motor.
Customized Solutions for All Working Conditions Benefiting from full-range power and voltage specifications, we develop dedicated heavy-duty motors for different scenarios: impact-resistant Motor for Crusher, high-torque low-speed Motor for Ball Mill, high-temperature continuous-operation Motor for Steel Mills, anti-corrosion explosion-proof Chemical Plant Motor, energy-saving low-noise HVAC Motor, and salt-fog resistant Marine Environment Motor. We can satisfy all customization demands for versatile Heavy-Duty Motor.

Full Technical Parameters

Power Range: 0.55KW ~ 20000KW (Custom high-power 3000KW+ motors available for mining, steel mill and ball mill applications)
Voltage Range: 380V Low Voltage ~ 13.8KV High Voltage (10000V high voltage Industrial Motor as standard configuration)
Frame Height: 355mm ~ 1120mm, covering small, medium and large-sized heavy-duty motor specifications

Premium Raw Material Configuration

As a professional manufacturer of high-voltage Industrial Motor, we adopt high-standard raw materials for all heavy-duty models including Mining Motor Application and Motor for Ball Mill:

Frame: High-strength cast iron or thickened steel plate (steel structure recommended for heavy-load working conditions for better deformation resistance)
Stator: Pure copper winding with excellent conductivity and low temperature rise for long-term full-load operation
Rotor: Optional copper bars or aluminum bars; copper rotors are standard for heavy-duty Motor for Crusher and Motor for Rolling Mill
Main Shaft: ASTM1045 carbon steel with quenching and tempering treatment, featuring excellent bending and torsion resistance for high-torque ball mill and rolling mill equipment
Bearings: Standard equipped with internationally renowned SKF & FAG bearings, with qualified domestic premium bearings as alternative options to extend the service life of each Heavy-Duty Motor.

Strict Full-Process Quality Control System

All testing instruments are calibrated annually. Every production procedure and finished Industrial Motor undergoes strict inspection from raw material incoming check to finished product delivery. Extra enhanced tests are arranged for heavy-duty motors such as Mining Motor Application and Motor for Steel Mills. Detailed inspection standards are listed below:

Component	Complete Inspection Items
Coil	1. Physical & chemical testing of copper wire raw materials2. Full-process patrol inspection during coil winding3. Dimensional precision test of formed coils
Iron Core	1. Verification of silicon steel mill test reports2. Inspection of lamination burrs and complete insulating paint film3. Tolerance testing of overall laminated core dimensions
Frame	1. Verification of qualification certificates for welded components2. Precision testing of finished machining sizes and flatness
Rotor (Core Component for Motor for Ball Mill & Motor for Crusher)	1. Compaction test of rotor laminated core2. Non-destructive testing for rotor bar high-temperature welding quality3. Full inspection of bar & end ring material, appearance, conductivity and dimensions4. Anti-loosening test of rotor bars inside slots5. Verification of rotor outer diameter and overall dimensions6. High-precision dynamic balance calibration to minimize heavy-load vibration
Main Shaft	1. Spectrum analysis of raw material composition & annealing process inspection2. Finished machining coaxiality and roughness testing
Stator	1. Compaction inspection of stator laminated core2. Dimension test of total & sectional core length3. Insulation integrity test during wire embedding4. Stator iron loss performance test
Final Assembly	1. Dimension and surface finish inspection of sliding bearings2. Uniformity of air gap, axial alignment of stator & rotor, clearance check between inner fan and wind shield3. Internal cleanliness inspection for dustproof & explosion-proof requirements (for Chemical Plant Motor & Mining Motor)4. Recheck of shaft center height and overall installation dimensions
Overall Performance Test	1. 100% routine test for all finished motors2. Type test sampling inspection for high-power Heavy-Duty Motor and custom application motors

Standard Factory Performance Testing

All Industrial Motor must pass a complete set of performance tests before delivery, with an official test report provided for each unit. Extra overload durability tests are added for heavy mining motors including Motor for Ball Mill and Motor for Crusher.

1. Routine Test (Mandatory for Every Motor)

Three-phase DC winding resistance, winding insulation resistance to ground, winding power frequency withstand voltage test, no-load current, no-load power, no-load loss, three-phase no-load current unbalance rate, locked-rotor current, locked-rotor torque, maximum output torque, rotation direction, triaxial vibration test (horizontal / vertical / axial), overall operating noise test, etc.

2. Type Test (Sampling for High-Power Heavy-Duty Motor & Custom Special Motors)

Full-load input power, full-load operating current, stator winding loss, rotor winding loss, core loss, mechanical loss, stray load loss, full-load slip ratio, stator winding temperature rise, steady bearing temperature, hot-state insulation resistance, long-time overload endurance test, full-load power factor and overall operational efficiency, to fully verify long-term reliability for Mining Motor Application and Motor for Steel Mills.

Advanced Coating Technology for Corrosion Resistance

Standard total film thickness reaches 120 microns (40 microns anti-corrosion primer + 80 microns wear-resistant topcoat), effectively resisting dust, moisture and salt fog erosion. Our certified professional painting team can customize any color according to factory environment and appearance demands. Double enhanced anti-corrosion coating is available for Marine Environment Motor and Chemical Plant Motor to strengthen corrosion resistance in offshore and chemical plant environments.

Export Packaging for Long-Distance Ocean Shipping

All exported Industrial Motor and Heavy-Duty Motor adopt standard ocean freight packaging solutions, including fumigation-free plywood cases and fumigated solid wood cases. Shockproof, moisture-proof and anti-collision design ensures intact delivery of large heavy-duty Motor for Ball Mill and Motor for Crusher to overseas mining, steel and chemical projects via transoceanic sea transportation and overland logistics.

Comprehensive Warranty & After-Sales Service

Standard Warranty Policy: 12 months from the date of on-site commissioning, or 18 months after factory shipment, whichever comes first. For Heavy-Duty Motor running 24/7 intensively such as Mining Motor Application and Motor for Rolling Mill, extended warranty plans are available upon consultation with our sales team. We provide long-term technical after-sales support and complete spare part supply.
